Hegawa DTS - Ductile Iron Tapping Saddle
are used to make permanent (hot) taps on existing of new pipe lines
Hegawa DTS – Ductile Iron Tapping Saddle
- For water and gaspipes
- Available Service outlets: 1/2″ up to including 2″Â + 1.1/2 ” Polva or 2″ Polva
- Strap Material: stainless steel grade AISI 304
- Strap width 60 mm, EPDM band
- Standard rubber gasket: NBR suitable for water and gas
- Supplied from DN40 up to and including DN600 with a strap widt 60mm
- Applicable for asbestos-cement, cast iron and steel
Hegawa DTS - Ductile Iron Tapping Saddle
The DTS saddle can be used to make taps on all pipe types except PE for water and gas applications
|
DN
|
working*
|
2" / Polva 2" not possible on these ranges
|
|---|---|---|
| range / mm | ||
| 40 | 44-57** | 2" / Polva 2" not possible on these ranges |
| 50 | 58-72** | 2" / Polva 2" not possible on these ranges |
| 60 | 72-82** | 2" / Polva 2" not possible on these ranges |
