Hegawa Grip Repair Clamp for PE pipes short

Complete with EPDM gaskets, Dacromet coated Bolts and Nuts. Epoxy coated (blue colour) 250 microns.

Suitable for a working pressure up to 10 bars
GJS 500-7 Ductile iron
Grip rings Brass CW671N
Gaskets : EPDM to EN 681-1, BS 6920
250Âµ Epoxy coating
Mechanical locking by means of grip rings in order to avoid pipe’s axial movement and breaking along the pipe

Complete with EPDM gaskets, Dacromet coated Bolts and Nuts. Epoxy coated (blue colour) 250 microns.

Nominal Size Wissen 50 65 80 100 125 150 200	Pipe outside diameter Wissen 63 75 90 110 125 140 160 200 225	L1 in mm Wissen 145 160 170 190 210 230 255 295 320	L2 in mm Wissen 175 180 195 215 250 310 345 480	Bolts Wissen 4 x M12 4 x M16 6 x M16	Product Code Hegawa Wissen GR.RC.S.063.E.D GR.RC.S.075.E.D GR.RC.S.090.E.D GR.RC.S.110.E.D GR.RC.S.125.E.D GR.RC.S.140.E.D GR.RC.S.160.E.D GR.RC.S.200.E.D GR.RC.S.225.E.D
50	63	145	175	4 x M12	GR.RC.S.063.E.D
65	75	160	180	4 x M12	GR.RC.S.075.E.D
80	90	170	480	4 x M12	GR.RC.S.090.E.D
100	110	190	195	4 x M12	GR.RC.S.110.E.D
125	125	210	195	4 x M12	GR.RC.S.125.E.D
125	140	230	215	4 x M16	GR.RC.S.140.E.D
150	160	255	250	6 x M16	GR.RC.S.160.E.D
200	200	295	310	6 x M16	GR.RC.S.200.E.D
200	225	320	345	6 x M16	GR.RC.S.225.E.D
