Hegawa FastFit Extra Wide Range Reducing Couplings

Complete with EPDM gaskets, Dacromet coated or Stainless Steel Bolts and Nuts. Epoxy coated (blue colour) 200 microns

Suitable for joining pipes of different rigid materials, such as cast iron, steel, asbestos cement, stainless steel, PVC, PE (insert required) and so on
PN-16 operational pressure
Middle ring : Nodular cast iron GGG 50 to EN 1514, EN 1563, BS 6920
Followers : Nodular cast iron GGG 50 to EN 1514, EN 1563, BS 6920
Gaskets : EPDM to EN 681-1, BS 6920
Bolts, Nuts and Washers : Steel F-114 quality 8.8. to DIN 931, DIN 934, DIN 9021, Dacromet coated
250Âµ Epoxy coating

Complete with EPDM gaskets, Dacromet coated or Stainless Steel Bolts and Nuts. Epoxy coated (blue colour) 200 microns.

Nominal Size Wissen *** = (Example RE.C.194.E.D. or RE.C.194.E.S) 200 250 300 350 400 450 500 600 E.D. = Dacromet B&B E.S. = Stainless steel B&N	Pipe outside diameter range in mm Wissen 194-226/216-246 244-276/266-297 315-345/345-375 375-405/400-435 400-435/435-470 475-510/530-565 499-534/530-565 530-565/575-610 575-610/610-645 610-645/645-680	L1 in mm Wissen 255 295 302	L2 in mm Wissen 368 419 499 565 600 695 740 775 810	Product Code Hegawa Wissen RE.C.194.* RE.C.244.* RE.C.315.* RE.C.375.* RE.C.400.* RE.C.475.* RE.C.499.* RE.C.530.* RE.C.575.* RE.C.610.*	Weight kg Wissen 20,78 23,42 31,52 40,76 43,50 53,00 53,50 57,50 59,00 59,50
200	194-226/216-246	255	368	RE.C.194.***	20,78
250	244-276/266-297	255	419	RE.C.244.***	23,42
300	315-345/345-375	255	499	RE.C.315.***	31,52
350	375-405/400-435	295	565	RE.C.375.***	40,76
400	400-435/435-470	302	600	RE.C.400.***	43,50
450	475-510/530-565	302	695	RE.C.475.***	53,50
500	499-534/530-565	302	695	RE.C.499.***	53,00
500	530-565/575-610	302	740	RE.C.530.***	57,50
600	575-610/610-645	302	775	RE.C.575.***	59,00
600	610-645/645-680	302	810	RE.C.610.***	59,50
E.D. = Dacromet B&B
E.S. = Stainless steel B&N
*** = (Example RE.C.194.E.D. or RE.C.194.E.S)
